Partitioned commercial burglary alarm control panels

Vista Panel.png


The VISTA-128BPT is a powerful member of the Honeywell family of commercial alarm panels, integrating burglary, CCTV and access control functions. Many features are available that extend the applications of the VISTA-128BPT while simplifying end-user operation.

The VISTA-128BPT and VISTA-128BPTSIA are listed for residential burglary, residential fire and commercial burglary applications (see agency listings in this document for more details). They are compatible with a wide range of AlarmNet communications products for alarm reporting, uploading /downloading and remote services.


  • Provides nine style-B hardwired zones

  • Supports up to 119 additional zones using a built-in polling (V-Plex®, multiplex) loop interface

  • Supports up to 127 wireless zones using up to two 5800 series wireless receivers (fewer if using hardwire and/or polling loop zones)

  • Provides one power-limited bell circuit delivering 1.7Amp (max) at 12VDC

  • Provides the ability to control eight separate partitions independently, each functioning as if it had its own separate control

  • Accommodates 150 user codes with seven authority levels

  • Accommodates 32 keypad macro commands per system

  • Keeps a log of up to 512 events

  • Supports up to 16 compatible two-wire smoke detectors on zone 1

  • Zone 7 may be used for keyswitch arming/disarming

  • Integrates with WIN-PAK access control systems to provide increased users, event log and scheduling

  • Supports V-Plex addressable VISTAKEY access control (up to eight doors and 250 cards)

  • Easily programmed and maintained by Compass Windows-based downloader

  • Supports up to 96 programmable outputs

  • Programmable to meet SIA false alarm prevention specifications. To meet UL approval for ANSI/SIA CP-01-2010, order part number V128BPTSIA

  • Supports up to six touchscreen Advanced User Interface (AUI) devices (6272 or later)

  • Smoke detector reset at keypad

  • Quick exit

  • Group bypass

  • Arm faulted

  • Event arming

  • Carbon monoxide (CO) zone type support

  • Expanded high-speed RS-232 capability for third party interface and automation

  • Internet upload/download over AlarmNet GSM and/or IP communicators over the panel's keypad (ECP) bus

  • Ringback support for AlarmNet communicators (confirmation of closing report)

  • 24-hour dialer test support for AlarmNet devices

  • Supports V-Plex Smart Contact feature for improved responsiveness on systems with many V-Plex zones

  • Telco line cut detection
